HP Compaq SP750

Removal and Replacement Procedures
4-33
RIMM Slot Locations
The Compaq Professional Workstation SP750 ships with an eight-RIMM slot memory
expansion board (four RIMM slots per memory channel).
Figure 4-33. Location of eight RIMM slots
Table 4-4
RIMM Slot Locations
Identifier RIMM Slot Memory Channel
1
RIMM Slot 1 Channel B
2
RIMM Slot 2 Channel A
3
RIMM Slot 3 Channel B
4
RIMM Slot 4 Channel A
5
RIMM Slot 5 Channel B
6
RIMM Slot 6 Channel A
7
RIMM Slot 7 Channel B
8
RIMM Slot 8 Channel A
