1-6
Compaq Professional Workstation SP750 Maintenance and Service Guide
As shown in Figure 1-3, the workstation provides seven drive bays. Bays 1 through 3 are
located in the 3.5-inch removable hard drive cage, which is located behind the side access panel
of the workstation. Drive bays 4 through 7 are located on the front of the workstation. The
drives support various drive configurations.
Table 1-3
Drive Bay Components
Item Component Description
1
Bay 1 Part of the removable hard drive cage. A 3.5-inch, third-height bay that
supports a 1.0-inch hard drive or a 1.6-inch hard drive.
2
Bay 2
Part of the removable hard drive cage. A 3.5-inch, third-height bay that
supports a 1.0-inch hard drive. Bay 2 is not available when a 1.6-inch hard
drive is installed in either bay 1 or bay 3.
3
Bay 3
Part of the removable hard drive cage. A 3.5-inch, third-height bay that
supports a 1.0-inch hard drive or a 1.6-inch hard drive.
4
Bay 4
5.25-inch, half-height bay that supports 1.0-inch or 1.6-inch storage
devices. Either a CD-ROM drive or DVD-ROM drive is shipped in bay 4.
5
Bay 5*
5.25-inch, half-height bay that supports 1.0-inch or 1.6-inch storage
devices.
6
Bay 6*
5.25-inch, half-height bay that supports 1.0-inch or 1.6-inch storage
devices.
7
Bay 7 3.5-inch, third-height bay that supports a 1.0-inch device. A standard
3.5-inch diskette drive is shipped in bay 7.
* An optional Zip drive can be installed in bay 5 or 6.
