4-14
Compaq Professional Workstation SP750 Maintenance and Service Guide
Figure 4-11. Disconnecting the cables from the CD-ROM drive
To replace the CD-ROM or DVD-ROM drive, reverse the above procedure.
CAUTION:
Use only 3/16-inch or 5-mm screws as guide screws. Longer screws can damage
the internal components of the drive. Be sure to transfer the guide screw from the old drive to
the new one. The screw is installed on the right front side of the drive. Note that extra guide
screws are provided on the side of the air plenum.
CAUTION:
When servicing the workstation, be sure cables are placed in their proper locations
during the reassembly process. Improper cable placement can damage the workstation.
