Illustrated parts catalog 14
Item Description
Original spare
part number
Modified spare
part number
Customer self repair
g) 3.0-GHz Intel® Xeon™
2-MB L2 cache LV* **
399764-001 — Yes
h) 3.2-GHz Intel® Xeon™
2-MB L2 cache* **
379428-001 — Yes
i) 3.4-GHz Intel® Xeon™ 2-
MB L2 cache* **
379429-001 — Yes
j) 3.6-GHz Intel® Xeon™ 2-
MB L2 cache* **
379430-001 — Yes
k) 3.8-GHz Intel® Xeon™
2-MB L2 cache* **
399133-001 — Yes
l) 2.83-GHz Intel® Xeon™
dual-core, 1066-MHz FSB,
4-MB cache (for use with
dual-core processor SAS
system board assembly
number 012977-001
only)* **
403934-001 — Yes
Boards
12 PPM, 12 V, 81 A 347884-001 — Yes
13 System board — — —
a) System board, with
processor cages and system
battery
392609-001 — Yes
b) System board, dual-core
processor support, SAS,
with processor cages and
system battery (for use with
Intel® Xeon™ dual-core
processor only)*
409160-001‡
See requirement
411030-001 Yes
14 Power converter module 392611-001 — Yes
15 SAS backplane, 8 bay
392610-001‡
See requirement
411024-001 Yes
16 Power button/LED board
366300-001‡
See requirement
411026-001 Yes
Media devices
17
Diskette drive, slimline,
1.44 MB (optional)
289550-001‡
See requirement
399311-001 Yes
18
CD-ROM drive, removable
slimline, IDE, 24X
228508-001‡
See requirement
399401-001 Yes
19
DVD-ROM drive, removable
slimline, 8X*
268795-001‡
See requirement
397928-001 Yes
Cables
20 SAS options cable kit* 392612-001 — —
a) Drive cage cable — — Yes
b) CD multi-bay cable — — Yes
21 SAS option cable* 389952-001 — Yes
