Illustrated parts catalog 15

Item Description

Original spare

part number

Modified spare

part number

Customer self repair

22 Signal cable kit* 228518-001 — —

a) Power button/LED board

cable, 14 pin

— — Yes

b) PCI hot-plug LED board

cable

— — Yes

Miscellaneous cable kit* 366063-001 — —

a) Diskette drive cable* — — Yes

b) CD multibay adaptor

cable*

— — Yes

c) USB cable and

connector*

— — Yes

Rack mounting

hardware

2U Quick Deploy Rail

System*

359254-001 — Yes

Miscellaneous

24 Hardware kit* 228527-001 — —

a) Screws, T-15, flat-head — — Yes

b) Expansion slot cover — — Yes

c) Screws, 6-32 — — Yes

25 Plastics kit* 359720-001 — —

a) PCI slot release lever — — Yes

b) PCI lightpipe, rear — — Yes

c) PCI lightpipe, cover — — Yes

d) PCI riser cage door latch — — Yes

e) Thumbscrew with molded

cap, PCI slot 1

— — Yes

f) Standoff — — Yes

g) Plastic standoff 0.134 in — — Yes

h) Battery clip — — Yes

i) PCI card guide retainer — — Yes

j) Thumbscrew knob — — Yes

k) Diskette drive slot cover — — Yes

26 AC power cord* 187335-001 — Yes

DVD/CD-ROM drive ejector

assembly*

371114-001 — Yes

PCI expansion board

ejector*

359261-001 — Yes

29 Battery, 3.3 V, lithium* 179322-001 — Yes

30 Country kit* 359722-001 — Yes
