HP EliteDesk 800 G1 Small Form Factor Service Manual

No. System Board Connector System Board Label Color Component
15 Power PWR white System Board
16 USB 3.0 FRONT USB3.0 blue Front USB 3.0 Ports
17 USB 3.0 MEDIA3.0 black USB 3.0 Device, such as a USB 3.0
Media Card Reader
18 SATA 3.0 SATA0 dark blue Primary Hard Drive
19 SATA 3.0 SATA1 light blue Any SATA Device other than the
Primary Hard Drive
20 SATA 3.0 SATA2 light blue Any SATA Device other than the
Primary Hard Drive
21 USB 2.0 MEDIA black USB 2.0 Device, such as a USB 2.0
Media Card Reader
Drives
Description Spare part number
Optical drives
DVD±RW drive 657958-001
DVD-ROM drive 608394-001
Blu-ray BD-RW SuperMulti XL Drive 719157-001
Hard drives
2 TB, 7200 rpm hard drive 616608-001
1 TB hard drive, hybrid SSD, 2.5-inch hard drive 724937-001
1 TB, 10000 rpm hard drive 719106-001
1 TB, 7200 rpm hard drive 613202-001
750 GB, 7200 rpm, 2.5-inch hard drive, hybrid SSD, 2.5-inch hard drive 719105-001
500 GB, 10000 rpm hard drive 683923-001
500 GB, 7200 rpm hard drive, self-encrypting (SED) 696442-001
500 GB hard drive, hybrid SSD, 2.5-inch hard drive 724938-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
128 GB Solid State Drive (SSD) 665961-001
32 GB mSATA drive, 2.5-inch 686616-001
32 GB mSATA drive 719566-001
108 Chapter 6 Removal and replacement procedures: Small Form Factor (SFF)
