Drives
Description Spare part number
Optical drives
DVD±RW drive 657958-001
DVD-ROM drive 608394-001
Blu-ray BD-RW SuperMulti XL Drive 719157-001
Hard drives
2 TB, 7200 rpm hard drive 616608-001
1 TB hard drive, hybrid SSD, 2.5-inch hard drive 724937-001
1 TB, 10000 rpm hard drive 719106-001
1 TB, 7200 rpm hard drive 613202-001
750 GB, 7200 rpm, 2.5-inch hard drive, hybrid SSD 719105-001
500 GB, 10000 rpm hard drive 683923-001
500 GB, 7200 rpm, 2.5-inch hard drive, self-encrypting (SED) 696442-001
500 GB, 7200 rpm hard drive 696442-001
500 GB hard drive, hybrid SSD, 2.5-inch hard drive 724938-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
128 GB Solid State Drive (SSD) 665961-001
32 GB mSATA drive 719566-001
32 GB mSATA drive, 2.5-inch 686616-001
When installing drives, follow these guidelines:
●
The primary Serial ATA (SATA) hard drive must be connected to the dark blue primary SATA
connector on the system board labeled SATA0.
●
Connect secondary hard drives and optical drives to any of the light blue SATA connectors on the
system board (labeled SATA1, SATA2, SATA3, and SATA5).
●
Connect a media card reader USB 3.0 cable to the USB connector on the system board labeled
MEDIA3.0.
●
The power cable for the drives has two branches coming off the system board connector. The first
branch is a three-headed cable with the first connector routed to the 5.25-inch bay, the second
connector routed to the 3.5-inch bay, and the third (two-wire) connector routed to the slim optical
drive bay. The second branch is a three-headed cable with the first connector routed to the bottom
Drives
59
To Next Page
