Hard drive
Description Spare part number
750 GB, 7200 rpm, hybrid SSD 719105-001
500 GB, 7200 rpm, self-encrypting (SED) 696442-001
500 GB, 7200 rpm 686217-001
320 GB, 7200 rpm 639135-001
500 GB, hybrid SSD 724938-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
128 GB Solid State Drive (SSD) 665961-001
32 MB mSATA drive 719566-001
NOTE: The Ultra-Slim Desktop supports only 2.5-inch Serial ATA (SATA) internal hard drives.
Before you remove the old hard drive, be sure to back up the data from the old hard drive so that you
can transfer the data to the new hard drive.
The 2.5-inch hard drive is enclosed in a carrier under the optical drive.
1. Prepare the computer for disassembly (
Preparation for disassembly on page 141).
2. Remove the access panel (
Access panel on page 142).
3. Remove the optical drive (
Removing the optical drive on page 151).
4. Press in the release latch on the left side of the hard drive carrier (1) then rotate the carrier handle
up (2).
154 Chapter 7 Removal and replacement procedures: Ultra-slim Desktop (USDT)
