HP EliteDesk 800 G1 Small Form Factor Service Manual

Power switch
Description Spare part number
Power switch 732767-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 141).
2. Remove the access panel (
Access panel on page 142).
3. Remove the front bezel (
Front bezel on page 143).
4. Remove the optical drive (
Removing the optical drive on page 151).
5. Remove the hard drive (
Hard drive on page 154).
6. Remove the drive cage (
Drive cage on page 164).
7. Disconnect the power switch cable from the system board connector labeled PB/LED.
8. Remove the power switch cable from atop the front I/O bracket.
9. From the front of the computer, press down (or squeeze) on the top on the power switch (1), and
then rotate it down (2) to disengage it from the chassis.
10. Pull the power switch and cable assembly out through the hole in the front of the chassis.
To install the power switch, reverse the removal procedure.
170 Chapter 7 Removal and replacement procedures: Ultra-slim Desktop (USDT)
