Access panel
Description Spare part number
Access panel 732763-001
To access internal components, you must remove the access panel:
1. Prepare the computer for disassembly (
Preparation for disassembly on page 141).
2. Loosen the thumbscrew on the rear of the computer (1), slide the access panel toward the rear of
the computer, then lift it off (2).
To install the access panel, reverse the removal procedure.
142 Chapter 7 Removal and replacement procedures: Ultra-slim Desktop (USDT)
