Optical drive
The Ultra-Slim Desktop uses a slimline Serial ATA (SATA) optical drive.
Description Spare part number
DVD-ROM drive 608394-001
DVD±RW drive 657958-001
Blu-ray BD-RW SuperMulti XL Drive 719157-001
Removing the optical drive
CAUTION: All removable media should be taken out of a drive before removing the drive from the
computer.
1. Prepare the computer for disassembly (Preparation for disassembly on page 141).
2. Remove the access panel (
Access panel on page 142).
3. Remove the front bezel (
Front bezel on page 143).
4. Disconnect the cables on the rear of the optical drive (1), push the green release latch on the right
rear side of the drive toward the center of the drive (2), then slide the drive forward and out of the
bay through the front bezel (3).
CAUTION: When removing the cables, pull the tab or connector instead of the cable itself to
avoid damaging the cable.
Optical drive
151
