HP EliteDesk 800 G1 Small Form Factor Service Manual

Misc boards
Description Spare part number
AMD Radeon HD 7650A 2GB MXM Graphics 708866-001
HP WLAN 802.11 a/b/g/n 2x2 PCIe NIC 695915-001
Sequential part number listing
Spare part
number
Description
487562-001 DisplayPort cable
587456-001 Heat sink for use with the processor (includes thermal material)
605163-001 Optical drive cable/connector
608394-001 DVD-ROM drive
612496-001 Stand
613766-001 180-W power adapter, standard
617450-001 Adapter, DisplayPort to HDMI
632484-001 Adapter, DisplayPort to VGA
636917-001 USB powered speakers
638816-001 Hood sensor
639135-001 320 GB, 7200 rpm hard drive
648964-001 AC adapter, 135W, standard
657958-001 DVD±RW drive
662723-001 Adapter, DisplayPort to DVI
665961-001 128-GB Solid-state drive
674315-001 Mouse, PS2, optical
674316-001 Mouse, USB, optical
674317-001 Mouse, wireless, HP Elite
674318-001 Mouse, USB, HP Elite
680020-001 256-GB Solid-state drive, self-encrypting (SED)
686217-001 500 GB, 7200 rpm hard drive
686616-001 32-GB Solid-state drive, 2.5-inch
689369-001 Heat sink for use on models with discrete graphics cards (includes thermal material)
689372-001 Memory module, 2-GB, PC3-12800
Ultra-Slim Desktop (USDT) chassis spare parts
33
