Front fan
Description Spare part number
Front fan 732765-001
The front fan sits against the front on the left side of the chassis.
1. Prepare the computer for disassembly (
Preparation for disassembly on page 141).
2. Remove the access panel (
Access panel on page 142).
3. Disconnect the fan control cable from the red system board connector labeled CHFAN (1).
4. Lift the fan straight up and out of the chassis (2).
To install the front fan, reverse the removal procedure.
150 Chapter 7 Removal and replacement procedures: Ultra-slim Desktop (USDT)
