HP EliteDesk 800 G1 Small Form Factor Service Manual

Misc boards
Description Spare part number
nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB 707252-001
nVidia Quadro NVS315 PCIe x16 graphics card, 1 GB 720837-001
AMD Radeon HD8490 PCIe x16 graphics card, 1 GB 717219-001
AMD Radeon HD8470 PCIe x16 graphics card, 2 GB DDR3 729085-001
AMD Radeon HD 8350 1GB PCIe x16 DH GFX 717220-001
AMD Radeon HD8350 PCIe x16 graphics card, 1 GB DDR3 729084-001
GeForce GT630 PCIe x16 graphics card, 2 GB 702084-001
Intel PRO/1000 single port GbE NIC, includes bracket 728562-001
HP WLAN 802.11 a/b/g/n 2x2 PCIe module 695915-001
Sequential part number listing
Spare part
number
Description
397117-001 Hard drive conversion bracket
460890-001 Foot kit
463023-001 DMS-59 to dual VGA cable
487562-001 DisplayPort cable
608394-001 DVD-ROM drive
613202-001 1 TB, 7200 rpm hard drive
616608-001 2 TB, 7200 rpm SATA hard drive
617450-001 Adapter, DisplayPort to HDMI
662723-001 Adapter, DisplayPort to DVI
632484-001 Adapter, DisplayPort to VGA
636917-001 USB powered speakers
638815-001 Serial port PCI card
638816-001 Hood sensor
638817-001 Printer port, PCI card
639959-001 Hard drive SATA cable, 17.7 inch, 2 straight ends
641498-001 Solenoid lock
643907-001 Fan sink (includes replacement thermal material)
Tower (TWR) chassis spare parts
19
