HP EliteDesk 800 G1 Small Form Factor Service Manual

Installing the new optical drive
NOTE: If you are installing an optical drive in a bay that did not previously have a drive in it, you
must remove the access panel and the bezel blank covering the opening of the bay before proceeding.
Follow the procedures in
Access panel on page 142 and Bezel blank on page 145.
1. Follow the instructions for removing the optical drive. Refer to Removing the optical drive
on page 151.
2. Attach the release latch to the new optical drive. Refer to
Preparing the new optical drive
on page 152.
3. Slide the optical drive through the front bezel all the way into the bay so that it locks in place (1),
then connect the cable to the rear of the drive (2).
Optical drive
153
