8-58 Parts and Diagrams
EN
Cable, Paper Feed/Tray 1
Pickup Solenoid
RG5-3703-000CN Table 8-7 on page 8-14
Cable, Sensor RG5-3711-000CN Table 8-21 on page 8-36
Cable, Top Cover Switch RG5-3705-000CN Table 8-7 on page 8-14
Cable, Tray 1 Sensor RG5-3700-000CN Table 8-7 on page 8-14
Clip, Left Side Panel RB1-8848-000CN Table 8-5 on page 8-10
Clip, Pickup Spring RB1-2190-000CN Table 8-22 on page 8-37
Clip, Right Side Panel RB1-8860-000CN Table 8-5 on page 8-10
Clutch, Separation Roller RB1-8974-000CN Table 8-23 on page 8-40
Connector VS1-6174-000CN Table 8-29 on page 8-49
Connector (250- and 500-
sheet Feeder)
VS1-6176-000CN Table 8-21 on page 8-36 and
Table 8-25 on page 8-44
Connector, Lower Tray (with
cable)
RG5-3712-000CN Table 8-21 on page 8-36
Control Panel RG5-2666-000CN Table 8-8 on page 8-17
Coupler, Pickup RB1-8877-000CN Table 8-22 on page 8-37
Coupler, Separation Roller RB1-8945-000CN Table 8-23 on page 8-40
Cover Assembly, Feeder, Left
Lower
RG5-2680-000CN Table 8-25 on page 8-44
Cover Assembly, Feeder, Left
Upper
RG5-2678-000CN Table 8-24 on page 8-41
Cover Assembly, Feeder, Right
Lower
RG5-2679-000CN Table 8-25 on page 8-44
Cover Assembly, Feeder,
Upper Right
RG5-2677-000CN Table 8-24 on page 8-41
Cover Assembly, Left RG5-2665-000CN Table 8-5 on page 8-10
Cover Assembly, Right Front RG5-2664-000CN Table 8-5 on page 8-10
Cover Envelope Feeder Drive RB2-2386-000CN Table 8-13 on page 8-25
Cover, Feeder PCA, 250-sheet
Tr ay
RB1-8907-000CN Table 8-25 on page 8-44
Cover, Feeder PCA, 500-sheet
Tr ay
RB1-8886-000CN Table 8-21 on page 8-36
Cover, Feeder, Left RG5-2669-000CN Table 8-21 on page 8-36
Table 8-33. Alphabetical Parts List (continued)
Description Part Number Table Number and Page
