A–4 Hardware and Software Guide
Specifications
The following table identifies the input and output signals
supported by the expansion port 2 on your notebook.
✎
Not all expansion products will support these features.
Feature Support
USB 2.0 Ye s
10/100 Ethernet Ye s
Gigabit Ethernet No
IEEE 1394 (4-pin port) Ye s
Consumer IR (for optional
remote control only)
Ye s
Power inputs 135 W/180 W*
Composite video Ye s
S-Video Ye s
Component video Ye s
S/PDIF audio Ye s
DVI No
Headphone/speaker audio-out Ye s
Microphone audio-in Ye s
*Refer to the rating marked on your notebook.
