Quality of Service (QoS): Managing Bandwidth More Effectively
Using QoS Classifiers To Configure QoS for Outbound Traffic
The DSCPs for this
example have not yet
been assigned an
802.1p priority level.
Figure 6-18. Display the Current DSCP-Map Configuration
2. Configure the policies in the DSCP table:
Figure 6-19. Example of Policies Configured (with Optional Names) in the DSCP
Table
3. Assign the policies to the codepoints in the selected packet types.
6-42

HP ProCurve 2610 Specifications

General

Switching Capacity	12.8 Gbps
Forwarding Rate	9.5 Mpps
MAC Address Table Size	8000 entries
Layer	Layer 2
RAM	64 MB
Flash Memory	16 MB
Jumbo Frame Support	Yes
Manageable	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 x 10/100
VLANs	256
Management	Web, CLI, SNMP
Power Supply	Internal
Operating Temperature	0°C to 40°C
Dimensions (W x D x H)	17.42 x 12.73 x 1.73 in
