Static Virtual LANs (VLANs)
Port-Based Virtual LANs (Static VLANs)
An asterisk indicates
you must reboot the
switch to implement
the new Maximum
VLANs setting.
Figure 2-12. VLAN Menu Screen Indicating the Need To Reboot the Switch
– If you changed the VLAN Support option, you must reboot the
switch before the Maximum VLANs change can take effect. You
can go on to configure other VLAN parameters first, but remem-
ber to reboot the switch when you are finished.
– If you did not change the VLAN Support option, a reboot is not
necessary.
4. Press [0] to return to the Main Menu.
Adding or Editing VLAN Names
Use this procedure to add a new VLAN or to edit the name of an existing VLAN.
1. From the Main Menu select:
2. Switch Configuration
8. VLAN Menu . . .
2. VLAN Names
If multiple VLANs are not yet configured you will see a screen similar to
figure 2-13:
2-17
