Quality of Service (QoS): Managing Bandwidth More Effectively
Using QoS Classifiers To Configure QoS for Outbound Traffic
For example, suppose that you want to prioritize inbound traffic on the
following source-ports:
Source-Port Priority
1 - 3 2
4 3
5, 8 5
9 - 11 6
1. Execute the following commands to prioritize traffic received on the
above ports.
Figure 6-28. Configuring and Displaying Source-Port QoS Priorities
2. Remove port 1 from QoS prioritization.
In this instance, No-
override indicates that port
A1 is not prioritized by QoS.
Figure 6-29. Returning a QoS-Prioritized VLAN to “No-override” Status
6-53
