HP ProCurve Series 2810 User Manual

5-5
Multiple Instance Spanning-Tree Operation
Overview
Note on Path Cost RSTP and MSTP implements a greater range of path costs and new default
path cost values to account for higher network speeds. These values are
different than the values defined by 802.1D STP as shown below.
Because the maximum value for the path cost allowed by 802.1D STP is 65535,
devices running that version of spanning tree cannot be configured to match
the values defined by MSTP, at least for 10 Mbps and 100 Mbps ports. In LANs
where there is a mix of devices running 802.1D STP, RSTP, and/or MSTP, you
should reconfigure the devices so the path costs match for ports with the same
network speeds.
Port Type 802.1D STP Path Cost RSTP and MSTP Path Cost
10 Mbps 100 2 000 000
100 Mbps 10 200 000
1 Gbps 5 20 000

HP ProCurve Series 2810 Specifications

General

Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
Jumbo Frame Support	Yes
Uplink Ports	4 x dual-personality ports (10/100/1000 or mini-GBIC)
Switching Capacity	48 Gbps
Throughput	35.7 Mpps
Forwarding Rate	35.7 million pps
Management	Web, SNMP, CLI
MAC Address Table Size	16000 entries
Routing Protocol	Static routing
Features	VLAN support, QoS, IGMP snooping
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	15% to 95% non-condensing
Model	HP ProCurve Series 2810
Ports	24 x 10/100/1000 (Gigabit)
