HP ProCurve Series 2810 User Manual

7-25
ProCurve Stack Management
Configuring Stack Management
4. To continue deleting the selected Member, press the Space bar once to
select Yes for the prompt, then press
[Enter] to complete the deletion. The
Stack Management screen updates to show the new stack Member list.
Using the Commander To Access Member Switches for
Configuration Changes and Monitoring Traffic
After a Candidate becomes a stack Member, you can use that stack’s
Commander to access the Member’s console interface for the same configu-
ration and monitoring that you would do through a Telnet or direct-connect
access.
1. From the Main Menu, select:
9. Stacking...
5. Stack Access
You will then see the Stack Access screen:
Figure 7-16. Example of the Stack Access Screen
Use the downarrow key to select the stack Member you want to access, then
press
[X] (for eXecute) to display the console interface for the selected Member.
For example, if you selected switch number 1 (system name:
Coral Sea) in figure
7-16 and then pressed
[X], you would see the Main Menu for the switch named
Coral Sea.
For status descriptions, see the table on page 7-48.

HP ProCurve Series 2810 Specifications

General

Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
Jumbo Frame Support	Yes
Uplink Ports	4 x dual-personality ports (10/100/1000 or mini-GBIC)
Switching Capacity	48 Gbps
Throughput	35.7 Mpps
Forwarding Rate	35.7 million pps
Management	Web, SNMP, CLI
MAC Address Table Size	16000 entries
Routing Protocol	Static routing
Features	VLAN support, QoS, IGMP snooping
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	15% to 95% non-condensing
Model	HP ProCurve Series 2810
Ports	24 x 10/100/1000 (Gigabit)
