HP ProCurve Series 2810 User Manual

7-19
ProCurve Stack Management
Configuring Stack Management
Using the Commander’s Menu To Manually Add a Candidate to a
Stack. In the default configuration, you must manually add stack Members
from the Candidate pool. Reasons for a switch remaining a Candidate instead
of becoming a Member include any of the following:
■ Auto Grab in the Commander is set to No (the default).
■ Auto Join in the Candidate is set to No.
Note: When a switch leaves a stack and returns to Candidate status, its
Auto Join parameter resets to No so that it will not immediately rejoin a
stack from which it has just departed.
■ A Manager password is set in the Candidate.
■ The stack is full.
Unless the stack is already full, you can use the Stack Management screen to
manually convert a Candidate to a Member. If the Candidate has a Manager
password, you will need to use it to make the Candidate a Member of the stack.
1. To add a Member, start at the Main Menu and select:
9. Stacking...
4. Stack Management
You will then see the Stack Management screen:
Figure 7-9. Example of the Stack Management Screen
2. Press
[A] (for Add) to add a Candidate. You will then see this screen listing
the available Candidates:
For status descriptions, see the table on page 7-48.

HP ProCurve Series 2810 Specifications

General

Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
Jumbo Frame Support	Yes
Uplink Ports	4 x dual-personality ports (10/100/1000 or mini-GBIC)
Switching Capacity	48 Gbps
Throughput	35.7 Mpps
Forwarding Rate	35.7 million pps
Management	Web, SNMP, CLI
MAC Address Table Size	16000 entries
Routing Protocol	Static routing
Features	VLAN support, QoS, IGMP snooping
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	15% to 95% non-condensing
Model	HP ProCurve Series 2810
Ports	24 x 10/100/1000 (Gigabit)
