Cabling 156
HPE H240 Smart Host Bus Adapter/Smart Array P440
Controller cabling
• 8SFF drive cages are installed in bays 1 and 2, and 2SFF drives and VGA/USB are installed in the
front of the server (H240 HBA only) — Connect the bay 2 8SFF drive cage cable, the 2SFF drive
Mini-SAS cable, and the VGA/USB cable to the H240 HBA.
