Operations 28
Install the access panel
1. Place the access panel on top of the server with the hood latch open. Allow the panel to extend past
the rear of the server approximately 1.25 cm (0.5 in).
2. Push down on the hood latch. The access panel slides to a closed position.
3. Tighten the security screw on the hood latch.
Access the product rear panel
To access the product rear panel, release the cable management arm and swing the arm away from the
rack as indicated.
Opening the cable management arm
To access the server rear panel:
1. Release the cable management arm.
