Removal and Replacement Procedures
ATAPI Tape Drive Cable Routing
Figure 2-9: ATAPI tape drive cable routing
Table 2-3: ATAPI Tape Drive Cable Routing
Item Connector
1 Integrated IDE channel
2 Device 1
3 Device 0
2-14 HP ProLiant ML310 Server Maintenance and Service Guide
