HP ProLiant ML310 Maintenance And Service Guide

Removal and Replacement Procedures
To replace the lithium battery on the system board:
1. Complete the preparation procedures. Refer to “Preparation Procedures” in this chapter.
2. Remove the access panel. Refer to “Access Panel” in this chapter.
3. Locate the battery on the system board.
NOTE: If you have expansion boards installed, it may be necessary to remove them to gain access to
the battery.
4. Press outward on the latch at the top of the battery holder to release the battery (1), and
then lift the battery away from the holder (2).
1
2
Figure 2-34: Locating and removing the battery from the SCSI
system board
1
2
Figure 2-35: Removing the battery from the ATA system board
2-40 HP ProLiant ML310 Server Maintenance and Service Guide

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
