Removal and Replacement Procedures
Power Supply
To remove the power supply:
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Unplug the power cord before removing the power supply from the server.
• Install the power supply before connecting the power cord to the power supply.
CAUTION: To avoid dropping the power supply, pull out and hold the power supply with a
firm grip.
1. Complete the preparation procedures. Refer to “Preparation Procedures” in this chapter.
2. Remove the access panel. Refer to “Access Panel” in this chapter.
3. Disconnect all power cables from the devices and system board.
4. Remove the four screws securing the power supply to the rear of the chassis (1).
5. Slide the power supply forward, and then lift the power supply from the chassis (2).
Figure 2-33: Removing the power supply
To replace the power supply, reverse steps 2 through 5.
2-38 HP ProLiant ML310 Server Maintenance and Service Guide
