HP ProLiant ML310 Maintenance And Service Guide

Removal and Replacement Procedures
Power Switch and LED
IMPORTANT: To completely remove all power from the server, you must disconnect the power cord
from the server.
To remove the power switch:
1. Complete the preparation procedures. Refer to “Preparation Procedures” in this chapter.
2. Remove the access panel. Refer to “Access Panel” in this chapter.
3. Disconnect the power switch cable from the system board.
Figure 2-17: Disconnecting the power switch cable from the system
board
2-24 HP ProLiant ML310 Server Maintenance and Service Guide

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
