HP xw6400 User Manual

D Appendix D — System board
designators
This appendix lists the system board designators for this system.
Designator Silkscreen Component
MH02-03, MH06-09, MH14-15 N/A Mounting holes
E14 BBLK_WP Boot block header/jumper
E49 PSWD Clear password header/jumper
J20 SLOT 5 PCI PCI slot
J21 SLOT 6 PCI PCI slot
J22 N/A PCI slot
J33 SLOT 4 PCI Express slot
J31 SLOT 2 PCI Express slot
J32 SLOT 3 PCI Express slot
J41 SLOT 1 PCI Express x16 slot for graphics
P60-63, P66-67 SATA0, SATA1, SATA2 SATA Connectors
J50, P53 PAR/SER Parallel port and serial port stack connector
J68 KBD MS PS2 Stacked keyboard/mouse connector
J9 RJ45/USB Stacked RJ 45/dual USB
J10 USB Quad stacked USB
J83 AUD Triple stacked audio jack
SW50 CMOS Clear CMOS switch/push button
P1 PWR Power supply connector (24-pin)
P3 PWRCPU Processor and memory 12V header
P10 FDD Diskette driver connector
P11 AUX Auxiliary audio connector
P20 PRIMARY IDE Primary IDE connector
P23 FRNT AUD Front panel audio header
P24 FRNT USB Front panel USB header
ENWW 161

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
