Table 1-6 Power supply current
Current Minimum Operating Continuous Maximum
3.3 V 0 A 0.5 A 18 A 20 A
5.1 V 0 A 0.5 A 18 A 20 A
12 VCPU0 0 A 3.1 A 17 A 19 A
12 VCPU1 0 A 3.1 A 10 A 15 A
12 V-D 0 A 3.1 A 12 A 15.5 A
12 V-B 0 A 3.1 A 15.5 A 18.8 A
V12N 0 A 0 A 0.2 A 0.3 A
5.08 VSB 0 A 0 A 2.1 A .32 A
WARNING! Do not exceed 110 W of combined power on 5 V and 3.3–V outputs.
Do not exceed 552 W of combined power on the 12–V (CPU0/CPU1/B/D) outputs.
Do not exceed 240 VA on any of the 12–V outputs (CPU0, CPU1, B, and D) power combination.
Do not exceed 575 W of total continuous output power.
Power supply specifications
Table 1-7 Power supply specifications
Power supply 575 W custom power supply (wide ranging, active PFC)
Operating voltage range 90–269 VAC
Rated voltage range
100–240 VAC 118 VAC
Rated line frequency 50/60Hz 400Hz
Operating line frequency range 47–66 Hz 393–407Hz
Rated input current 10A @ 100–120 VAC
6A @ 200–240 VAC
9.7 @ 118 VAC
Heat dissipation
(Configuration and software dependent
Typical 980 BTU/hr
Maximum 3413 BTU/hr
(247 kg-cal/hr)
(860 kg-cal/hr)
Power supply fan 92x25 mm variable speed
FEMP standby power compliant @ 115V
(<2 W in S5 - power off)
Yes
ENWW Product specifications 7
