5. Dislodge the metal clip from the chassis by rocking the power button back and forth. Then slide
the power button assembly 2 out from the front of the chassis.
6. Slide the power button assembly out from the front of the chassis.
Figure 4-12 Removing the power button
To replace the power button, reverse the previous steps.
To remove the speaker:
1. Disconnect the speaker cable from the in-line front panel I/O device assembly cable, if you have
not already done so.
2. Slide the speaker away from the three flanges and remove it from the chassis.
Figure 4-13 Removing the speaker
To replace the speaker, reverse the previous steps.
Memory fan
CAUTION HP only ships DIMMs that are electrically and thermally compatible with this product.
Because third-party DIMMs might not be not be compatible, they are not supported by HP.
ENWW Removal and replacement of components 69
