Product features
Component view
The following image shows a typical HP xw6400 workstation. Drive configurations can vary.
For complete and current information on supported accessories and components, see
http://partsurfer.hp.com.
Figure 1-1 Component view
Table 1-1 Component view
Item Description Item Description
1 CPU heatsinks 9 Speaker
2 Memory module 10 PCI Express graphics card
3 Power supply 11 Hard drive
4 Top cover 12 Side access panel
5 Optical drive 13 Processors
6 Front bezel 14 System fans
7 Chassis 15 Memory fan
8 System board
2 Chapter 1 Product overview ENWW
