HP xw6400 User Manual

Product specifications
The following table lists the physical dimensions for the HP xw6400 Workstation.
Table 1-4 Physical characteristics
Weight (typical
configuration)
16 kg (35 lb)
Tower dimensions 441 mm (17.4 in.) tall
165 mm (6.5 in.) wide
440 mm (17.3 in.) deep
Rack-mount dimensions
(top cover and foot removed)
165 mm (6.5 in.) tall, less than 4U
425 mm (16.75 in.) wide (fits in a standard 19-in. rack)
440 mm (17.3 in.) deep
Power supply
This section describes power supply specifications for the HP xw6400 Workstation.
●
+3.3V—PCI, MCH, ICH5, PXH, LAN, SATA, and SAS hard drives, and on-board logic
●
+5V—Storage (disk, optical, diskette), PCI, audio, USB, input to on-board regulator, and on-board
logic
●
+12V-B-—PCI, fans, and input to on-board regulators that supply 1.2V
●
+12V-D—Storage (disk, optical, diskette), PCI Express x16 auxiliary connector
●
+12VCPU0—Input to on-board regulator that supplies power for CPU0 and input to on-board
regulators that supply 1.5 V and 1.8 V to memory slots
●
+12VCPU1—Input to on-board regulator that supplies power for CPU1
●
-12V—PCI
●
5VSB—Standby mode circuitry
Table 1-5 Power supply voltage
Voltage Minimum Maximum
3.3 V 3.2 V 3.5 V
5.1 V 4.8 V 5.3 V
12 VCPU0 11.5 V 12.6 V
12 VCPU1 11.5 V 12.6 V
12 V-A 11.5 V 12.6 V
12 V-D 11.5 V 12.6 V
V12N –10.9 V –13.2 V
5.08 VSB 4.8 V 5.3 V
6 Chapter 1 Product overview ENWW

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
