HP xw6400 User Manual

Figure 4-9 Removing the hood sensor
To replace the hood sensor, reverse the previous steps.
Hood lock (Smart cover lock) (optional)
To remove the hood lock:
1. Disconnect power from the system (
Predisassembly procedures on page 57), remove the side
access panel (
Side access panel on page 63), and remove the top cover (Top cover on page 65).
2. Using the FailSafe key, remove the two tamper-resistant screws that secure the hood lock to the
chassis.
Figure 4-10 Removing the hood lock
3. Disconnect the hood lock cable from the system board and remove the lock assembly.
To install the hood lock, reverse the previous steps.
ENWW Removal and replacement of components 67

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
