HP xw6400 User Manual

B Appendix B — SATA devices
This appendix describes how to use the Intel Matrix Storage Manager option ROM Configuration Utility
to set up and manage SATA RAID volumes.
NOTE If only a single HDD is attached, the Intel Matrix Storage Manager option ROM will not
execute. All associated messages will not be displayed.
The Intel Serial ATA AHCI BIOS always executes when RAID/AHCI is selected for the SATA
emulation mode. This BIOS is only used to support serial attached optical drives. When an HDD
is attached, the AHCI BIOS properly identifies the HDD that is connected to the appropriate SATA
port and displays Device not supported in this configuration. This message is expected and
does not indicate a problem.
ENWW 145

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
