Front panel components
The following image shows a typical HP xw6400 Workstation. Drive configurations can vary.
Figure 1-2 Front panel components
Table 1-2 Front panel components
Item Description Item Description
1 Optical drive 7 Power button
2 Optical drive activity light 8 Hard drive activity light
3 Optical drive eject button 9 USB connectors (2)
4 5.25-inch drive bay 10 Headphone connector
5 3.5-inch drive bay 11 Microphone connector
6 Power on light 12 IEEE-1394a connector (optional)
ENWW Product features 3
