42
Item HPE 5710-54HF HPE 5710-30HF
Minimum
power
consumption
PSR250-12A/PSR250-12A1:
Single AC input: 66 W
Dual AC inputs: 74 W
PSR450-12A/PSR450-12A1:
Single AC input: 68 W
Dual AC inputs: 76 W
PSR450-12D:
Single DC input: 68 W
Dual DC inputs: 73 W
PSR250-12A/PSR250-12A1:
Single AC input: 66 W
Dual AC inputs: 74 W
PSR450-12A/PSR450-12A1:
Single AC input: 67 W
Dual AC inputs: 76 W
PSR450-12D:
Single DC input: 68 W
Dual DC inputs: 74 W
Maximum
power
consumption
PSR250-12A/PSR250-12A1:
Single AC input: 171 W
Dual AC inputs: 178 W
PSR450-12A/PSR450-12A1:
Single AC input: 169 W
Dual AC inputs: 178 W
PSR450-12D:
Single DC input: 169 W
Dual DC inputs: 176 W
PSR250-12A/PSR250-12A1:
Single AC input: 130 W
Dual AC inputs: 134 W
PSR450-12A/PSR450-12A1:
Single AC input: 130 W
Dual AC inputs: 138 W
PSR450-12D:
Single DC input: 133 W
Dual DC inputs: 140 W
Chassis
leakage
current
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943
Melting
current of
power supply
fuse
PSR250-12A/PSR250-12A1: 6.3 A @ 250 VAC
PSR450-12A/PSR450-12A1: 10 A @ 250 VAC
PSR450-12D: 20 A @ 125 VDC
Operating
temperature
0°C to 45°C (32°F to 113°F)
Operating
humidity
10% RH to 90% RH, noncondensing
Fire
resistance
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943
Table 10 Technical specifications (2)
Item HPE 5710-54HT HPE 5710-30HT
Dimensions
(H × W × D)
44 × 440 × 460 mm (1.73 × 17.32 ×
18.11 in)
44 × 440 × 460 mm (1.73 × 17.32 × 18.11 in)
Weight 10 kg (22.05 lb) 10 kg (22.05 lb)
Console ports
1 × mini USB console port
1 × serial console port
1 × mini USB console port
1 × serial console port
Management
Ethernet ports
1 × 10M/100M/1000MBASE-T
copper port
1 × SFP port
1 × 10M/100M/1000MBASE-T copper port
1 × SFP port
USB ports 1 1
