HPE FlexFabric 5710 Series User Manual

47
Appendix C Ports and LEDs
Ports
Console port
The switch has two console ports: serial console port and Mini USB console port.
Table 14 Console port specifications
Item Console port Mini USB console port
Connector type RJ-45 USB mini-Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII
terminal.
• Provides connection to the serial
port of a local or remote (through
a pair of modems) PC running
terminal emulation program.
• Provides connection to an ASCII
terminal.
• Provides connection to the USB
port of a local PC running terminal
emulation program.
Management Ethernet port
The switch provides a copper and a fiber management Ethernet port.
You can connect this port to a PC or management station for loading and debugging software or
remote management.
Table 15 Copper management Ethernet port specifications
Item Specification
Connector type RJ-45
Connector quantity 1
Port transmission rate 10/100/1000 Mbps, half/full duplex
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
Table 16 Fiber management Ethernet port specifications
Item Specification
Connector type LC
Connector quantity 1
Port transmission rate 100/1000 Mbps, full duplex
Transmission medium and max
transmission distance
See Table 17 and Table 18.

HPE FlexFabric 5710 Series Specifications

General

Model	HPE FlexFabric 5710 Series
Power Supply	AC or DC
Operating Temperature	0°C to 45°C
Routing Protocol	OSPF, BGP, RIP
Input Voltage	100-240V AC
Operating Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Up to 9216 bytes
Management	CLI, SNMP
