HPE FlexFabric 5710 Series User Manual

55
Figure 57 QSFP28 copper cable
Figure 58 QSFP28 fiber cable
NOTE:
As a best practice, use HPE QSFP28 transceiver modules, QSFP28 cables, QSFP+ transceiver
modules, or QSFP+ cables (except for the QSFP+ to 4 × SFP+ cables) for the QSFP28 ports on the
switch. The HPE QSFP28 transceiver modules or QSFP28 cables are subject to change over time.
For the most up-to-date list of QSFP28 transceiver modules or QSFP28 cables, contact Hewlett
Packard Enterprise Support or marketing staff.
1/10GBASE-T autosensing Ethernet port
The HPE 5710-54HT switch provides 1/10GBASE-T autosensing Ethernet ports.
Table 29 1/10GBASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Port transmission rate 1/10 Gbps, full duplex, MDI/MDI-X autosensing
Transmission medium and max
transmission distance
• 55 m (180.45 ft) over category-6 unshielded twisted pair cable
• 100 m (328.08 ft) over category-6 shielded twisted pair cable
• 100 m (328.08 ft) over category-6A or above twisted pair cable
Compatible standards
• IEEE 802.3ab
• IEEE 802.3an
To avoid interference between cables, layer cables as follows:
• Use category-6A or above cables and connectors.
• Do not bundle cables in their first 20 m (65.62 ft).
• Separate power cords and twisted pair cables at and around the distribution frame.

HPE FlexFabric 5710 Series Specifications

General

Model	HPE FlexFabric 5710 Series
Power Supply	AC or DC
Operating Temperature	0°C to 45°C
Routing Protocol	OSPF, BGP, RIP
Input Voltage	100-240V AC
Operating Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Up to 9216 bytes
Management	CLI, SNMP
