54
Table 26 QSFP28 transceiver modules available for the QSFP28 ports
Product
code
HPE
description
Central
wavelength
(nm)
Conne
ctor
Fiber
type and
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
JL274A
HPE X150
100G QSFP28
MPO SR4
100m MM
Transceiver
840 to 860 MPO
Multi-mode,
50/125
2000 70 m (229.66 ft)
4700
100 m (328.08
ft)
JH420A
HPE X150
100G QSFP28
MPO PSM4
500m SM
Transceiver
1295 to 1325 MPO
Single-mod
e, 9/125
N/A
0.5 km (0.31
miles)
JL275A
HPE X150
100G QSFP28
LC LR4 10km
SM Transceiver
Four lanes:
1294.53 to
1296.59
1299.02 to
1301.09
1303.54 to
1305.63
1308.09 to
1310.19
LC
Single-mod
e, 9/125
N/A
10 km (6.21
miles)
JH673A
HPE X150
100G QSFP28
CWDM4 2km
SM Transceiver
Four lanes:
1264.5 to
1277.5
1284.5 to
1297.5
1304.5 to
1317.5
1324.5 to
1337.5
LC
Single-mod
e, 9/125
N/A
2 km (1.24
miles)
Table 27 QSFP28 cables available for the QSFP28 ports
Product Code HPE description Cable length
JL271A HPE X240 100G QSFP28 to QSFP28 1m Direct Attach Copper Cable 1 m (3.28 ft)
JL272A HPE X240 100G QSFP28 to QSFP28 3m Direct Attach Copper Cable 3 m (9.84 ft)
JL273A HPE X240 100G QSFP28 to QSFP28 5m Direct Attach Copper Cable 5 m (16.40 ft)
Table 28 QSFP28 fiber cables available for the QSFP28 ports
Product
Code
HPE description Cable length
Data
rate
JL276A HPE X2A0 100G QSFP28 to QSFP28 7m Active Optical Cable 7 m (22.97 ft)
100
Gbps
JL277A HPE X2A0 100G QSFP28 to QSFP28 10m Active Optical Cable 10 m (32.81 ft)
JL278A HPE X2A0 100G QSFP28 to QSFP28 20m Active Optical Cable 20 m (65.62 ft)
