HPE FlexFabric 5710 Series User Manual

49
Product
code
HPE
description
Central
wavelength
(nm)
Connec
tor
Cable/Fiber
type and
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
JD119B
HPE X120 1G
SFP LC LX
Transceiver
1310 LC
Single-mode,
9/125
N/A
10 km (6.21
miles)
Multi-mode,
50/125
500 or 400
550 m (1804.46
ft)
Multi-mode,
62.5/125
500
550 m (1804.46
ft)
JD061A
HPE X125 1G
SFP LC LH40
1310nm
Transceiver
1310 LC
Single-mode,
9/125
N/A
40 km (24.86
miles)
JD062A
HPE X120 1G
SFP LC LH40
1550nm
Transceiver
1550 LC
Single-mode,
9/125
N/A
40 km (24.86
miles)
JD063B
HPE X125 1G
SFP LC LH80
Transceiver
1550 LC
Single-mode,
9/125
N/A
80 km (49.71
miles)
Table 19 10-Gigabit SFP+ transceiver modules available for the SFP+ ports
Product
code
HPE
description
Central
wavelength
(nm)
Connec
tor
Fiber type
and
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
JD092B
HPE X130
10G SFP+
LC SR
Transceiver
850 LC
Multi-mode,
50/125
2000
300 m (984.25
ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
JD094B
HPE X130
10G SFP+
LC LR
Transceiver
1310 LC
Single-mode,
9/125
N/A
10 km (6.21
miles)
Table 20 SFP+ cables available for the SFP+ ports
Product code HPE description
Max transmission
distance
Data rate
JD095C HPE X240 10G SFP+ SFP+ 0.65m DA Cable 0.65 m (2.13 ft)
10.31 Gbps
JD096C HPE X240 10G SFP+ SFP+ 1.2m DA Cable 1.2 m (3.94 ft)
JD097C HPE X240 10G SFP+ SFP+ 3m DA Cable 3 m (9.84 ft)
JG081C HPE X240 10G SFP+ SFP+ 5m DA Cable 5 m (16.40 ft)

HPE FlexFabric 5710 Series Specifications

General

Model	HPE FlexFabric 5710 Series
Power Supply	AC or DC
Operating Temperature	0°C to 45°C
Routing Protocol	OSPF, BGP, RIP
Input Voltage	100-240V AC
Operating Humidity	10% to 90% (non-condensing)
Jumbo Frame Support	Up to 9216 bytes
Management	CLI, SNMP
