Configuring a port to operate in manual voice VLAN
assignment mode
Configuration restrictions and guidelines
When you configure a port to operate in manual voice VLAN assignment mode, follow these
restrictions and guidelines:
• You can configure different voice VLANs on different ports on the same device. Make sure the
following requirements are met:
{ One port can be configured with only one voice VLAN.
{ Voice VLANs must be existing static VLANs.
• Do not enable voice VLAN on the member ports of a link aggregation group. For more
information about link aggregation, see "Configuring Ethernet link aggregation."
• For a port that is enabled with voice VLAN and operating in manual mode, you must manually
assign the port to the voice VLAN to make the voice VLAN take effect.
Configuration procedure
To configure a port to operate in manual voice VLAN assignment mode:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. (Optional.) Enable the voice
VLAN security mode.
voice-vlan security enable
By default, the voice VLAN
security mode is enabled.
3. (Optional.) Add an OUI
address for voice packet
identification.
voice-vlan mac-address
oui
mask
oui-mask
[
description
text
]
By default, system default OUI
addresses exist. For more
information, see Table 10.
4. Enter Layer 2 Ethernet
interface view.
interface
interface-type
interface-number
N/A
5. Configure the port to operate
in manual voice VLAN
assignment mode.
undo voice-vlan mode auto
By default, the manual voice
VLAN assignment mode is
disabled.
6. Assign the access, trunk, or
hybrid port in manual voice
VLAN assignment mode to
the voice VLAN.
• For the access port, see
"Assigning an access port to
a VLAN."
•
For the trunk port, see
"Assigning a trunk port to a
VLAN."
•
For the hybrid port, see
"Assigning a hybrid port to a
VLAN."
After y
ou assign an access port to
the voice VLAN, the voice VLAN
becomes the PVID of the port.
7. (Optional.) Configure the
voice VLAN as the PVID of
the trunk or hybrid port.
• For the trunk port, see
"Assigning a trunk port to a
VLAN."
•
For the hybrid port, see
"Assigning a hybrid port to a
VLAN."
T
his step is required for untagged
incoming voice traffic and
prohibited for tagged incoming
voice traffic.
8. Enable the voice VLAN
feature on the port.
voice-vlan
vlan-id
enable
By default, the voice VLAN
feature is disabled.
