52
Step Command Remarks
enable
To enable link-aggregation traffic redirection for an aggregation group:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter aggregate interface
view.
interface bridge-aggregation
interface-number
N/A
3. Enable link-aggregation
traffic redirection for the
aggregation group.
link-aggregation lacp
traffic-redirect-notification
enable
By default, link-aggregation traffic
redirection is disabled for an
aggregation group.
Displaying and maintaining Ethernet link
aggregation
Execute display commands in any view and reset commands in user view.
Task Command
Display information for an aggregate interface
or multiple aggregate interfaces.
display interface
[
bridge-aggregation
] [
brief
[
down
] ]
display interface
[
bridge-aggregation
[ interface-number ] ] [
brief
[
description
] ]
Display the local system ID.
display lacp system-id
Display the global or group-specific
link-aggregation load sharing modes.
display link-aggregation load-sharing mode
[
interface
[
bridge-aggregation
interface-number ] ]
Display detailed link aggregation information
for link aggregation member ports.
display link-aggregation member-port
[ interface-list ]
Display summary information about all
aggregation groups.
display link-aggregation summary
Display detailed information about the
specified aggregation groups.
display link-aggregation
verbose
[
bridge-aggregation
[ interface-number ] ]
Clear LACP statistics for the specified link
aggregation member ports.
reset lacp statistics
[
interface
interface-list ]
Clear statistics for the specified aggregate
interfaces.
reset counters interface
[
bridge-aggregation
[ interface-number ] ]
Ethernet link aggregation configuration examples
Layer 2 static aggregation configuration example
Network requirements
On the network shown in Figure 12, perform the following tasks:
• Configure a Layer 2 static aggregation group on both Device A and Device B.
