HPE OfficeConnect 1950 Series

33
(5) 1/10GBase-T auto-sensing Ethernet port (6) System status LED (SYS)
(7) RPS status LED (RPS) (8) 1/10GBase-T Ethernet port LED
(9) SFP+ port LED
Figure 36 Rear panel
(1) AC-input power receptacle (2) Grounding screw
HPE 1950 24G 2SFP+ 2XGT PoE+(370W)
Figure 37 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) SFP+ port
(3) 1/10GBase-T auto-sensing Ethernet port (4) Console port
(5) Port LED mode switching button (6) 10/100/1000Base-T Ethernet port LED
(7) SFP+ port LED (8) System status LED (SYS)
(9) RPS status LED (RPS) (10) 1/10GBase-T Ethernet port LED
(11) Port mode LED
Figure 38 Rear panel
(1) AC-input power receptacle (2) RPS receptacle
(3) Grounding screw
