SFP+ port LED
• The HPE 1950 12XGT 4SFP+, HPE 1950 48G 2SFP+ 2XGT, and HPE 1950 48G 2SFP+ 2XGT
PoE+(370W) switches provide a double-color (green and yellow) LED for each SFP+ port to
indicate its operating status.
Table 27 SFP+ port double-color LED description
Status Description
Steady green
A transceiver module is installed in the port. The port is operating at 10
Gbps and a link is present on the port.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module is installed in the port. The port is operating at 1 Gbps
and a link is present on the port.
Flashing yellow (not 3
Hz)
The port is sending or receiving data at 1 Gbps.
Flashing yellow (3 Hz) The port has failed POST.
Off
• No transceiver module is installed in the port, or no link is present on
the port.
• The port mode LED is operating in PoE mode (applicable to the PoE
switch models.)
• The HPE 1950 24G 2SFP+ 2XGT and HPE 1950 24G 2SFP+ 2XGT PoE+(370W) switches
provide two single-color LEDs for each SFP+ port to indicate its operating status.
Table 28 Description for the two single-color LEDs for the SFP+ port
LED Status Description
Green LED
Steady on
A transceiver module is installed in the port. The port is
operating at 10 Gbps, and a link is present on the port.
Flashing The port is sending or receiving data at 10 Gbps.
Off
• No transceiver module is installed in the port, or no
10 Gbps link is present on the port.
• The port mode LED is operating in PoE mode
(applicable to the PoE switch models.)
Yellow LED
Steady on
A transceiver module is installed in the port. The port is
operating at 1 Gbps, and a link is present on the port.
Flashing (not 3 Hz) The port is sending or receiving data at 1 Gbps.
Flashing (3 Hz) The port has failed POST.
Off
• No transceiver module is installed in the port, or no
1 Gbps link is present on the port.
• The port mode LED is operating in PoE mode
(applicable to the PoE switch models.)

HPE OfficeConnect 1950 Series Specifications

General

Model	HPE OfficeConnect 1950 Series
Switch Type	Managed
Layer	Layer 2/3
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Routing Protocol	Static, RIP, OSPF
Operating Temperature	0°C to 45°C
QoS Support	Yes
Ports	24 or 48 Gigabit Ethernet ports
10G Ports	Optional 2 or 4 SFP+ ports
PoE Support	Yes
Stacking	Yes (up to 4 switches)
Management	Web-based, SNMP, CLI
Security	802.1X, ACLs, Port Security
Forwarding Rate	Up to 131 Mpps
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Humidity	10% to 90% non-condensing
