HPE OfficeConnect 1950 Series Getting Started Guide

45
Switch
model
Port mode
LED (Mode)
status
LED LED Description
Yellow LED
Steady on
The port is operating at 10/100
Mbps, and a link is present on the
port.
Flashing (not
3 Hz)
The port is sending or receiving
data at 10/100 Mbps.
Flashing
yellow (3 Hz)
The port has failed POST.
Off
No link is present on the port, or
the port is not operating at 10/100
Mbps.
Flashing
green (PoE
mode)
Green LED
Steady on
The port is supplying PoE
correctly.
Flashing (3
Hz)
• The PD power requirement
exceeds the port PoE
capacity.
• The port fails to meet the
power requirement of the
PD because of power
insufficiency of the switch.
Off
The port is not supplying PoE
power.
Yellow LED
Steady on
A non-PD device is attached to
the port, or the port is
experiencing a PoE failure.
Flashing (3
Hz)
The port has failed POST.
Off
The port is not supplying PoE
power.
1/10GBase-T autosensing Ethernet port LEDs
Table 26 1/10GBase-T autosensing Ethernet port LED description
Status Description
Steady green The port has a link and is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow The port has a link and is operating at 1 Gbps.
Flashing yellow (not 3 Hz) The port is sending or receiving data at 1 Gbps.
Flashing yellow (3 Hz) The port has failed POST.
Off
• No link is present on the port.
• The port mode LED is operating in PoE mode (applicable to
the PoE switch models.)

HPE OfficeConnect 1950 Series Specifications

General

Model	HPE OfficeConnect 1950 Series
Switch Type	Managed
Layer	Layer 2/3
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Routing Protocol	Static, RIP, OSPF
Operating Temperature	0°C to 45°C
QoS Support	Yes
Ports	24 or 48 Gigabit Ethernet ports
10G Ports	Optional 2 or 4 SFP+ ports
PoE Support	Yes
Stacking	Yes (up to 4 switches)
Management	Web-based, SNMP, CLI
Security	802.1X, ACLs, Port Security
Forwarding Rate	Up to 131 Mpps
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Humidity	10% to 90% non-condensing
