hpmont HD3N-TC Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HD3N-TC Series Inverter User Manual V1.0 ―3―
Chapter 2 Product Information
2.1 Product Information
Model Motor (kW)
Rated capacity
(kVA)
Rated input
current (A)
Rated output
current (A)
Size
Single/Three phase power supply: 200 - 240V, 50/60Hz
HD3N-2D0P7G-TC 0.75 1.5 10.5 4.0 Frame 1
HD3N-2D1P5G-TC 1.5 2.8 18.5 7.5 Frame 1
Three phase power supply: 380 - 460V, 50/60Hz
HD3N-4T0P4G-TC 0.4 1.0 1.8 1.4 Frame 1
HD3N-4T0P7G-TC 0.75 1.5 3.4 2.3 Frame 1
HD3N-4T1P5G-TC 1.5 2.5 5.2 3.8 Frame 1
HD3N-4T2P2G-TC 2.2 3.4 7.3 5.1 Frame 1
HD3N-4T4P0G-TC 4.0 5.9 11.9 9.0 Frame 2
HD3N-4T5P5G-TC 5.5 8.5 15 13 Frame 2
HD3N-4T7P5G-TC 7.5 11 19 17 Frame 3
HD3N-4T011G-TC 11 16 28 25 Frame 3
HD3N-4T015G-TC 15 21 35 32 Frame 4
HD3N-4T018G-TC 18.5 24 39 37 Frame 4
