hpmont HD3N-TC Series User Manual

Chapter 5 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
―28― HD3N-TC Series Inverter User Manual V1.0
5.1 Group d: Display Parameter
Group d is status display parameter.
5.1.1 d00: Status Display Parameter
Ref. code Name Description Setting Range [Default]
d00.00 Inverter series [Actual value]
d00.01 Software version of inverter [Actual value]
d00.03 Non-standard software version of inverter [Actual value]
d00.06 Customized serial number [Actual value]
d00.07 Motor and control mode [Actual value]
Displays present motor and control mode.
Units: Current driving motor
• 0: Motor 1.
• 1: Motor 2.
Tens: Control mode
• 0: V/f control without PG.
• 1: Vector control 1without PG.
• 2,6: Vector control 2/3without PG.
d00.08 Rated current of inverter (A) [Actual value]
d00.10 Inverter status [Actual value]
Displays the inverter status, as following:
Thous
ands
Bit15: Unused Bit14: Unused
Bit13: Software
current restriction
0: Do not restrict
1: Restrict
Bit12: Stall
overvoltage
0: Invalid
1: Valid
Hundr
eds
Bit11: Unused
Bit10: Speed
limitation
0: Below limitation
1: Above limitation
Bit9: Unused
Bit8: Auto-tuning
0: Not in auto-tuning
1: In auto-tuning
Tens
Bit7: Unused Bit6: Unused
Bit5&Bit4: Acc/Dec/Constant
00: Constant
11: Constant
01: Acc
10: Dec
Units
Bit3: Zero speed
0: Invalid
1: Valid
Bit2: Forward/Reverse
0: Forward
1: Reverse
Bit1: Run/Stop
0: Stop
1: Run
Bit0: Inverter fault
0: Faulty
1: Normal
123
d00.11 Main setting frequency channel [Actual value]
0: Keypad.
1: Terminal.
2: Communication.
6 - 7: AI1 - AI2.
10: Potentionmeter on keypad.
12: Multi-speed.
d00.14 Setting frequency (Hz) [Actual value]
