hpmont HD3N-TC Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Function Introduction
HD3N-TC Series Inverter User Manual V1.0 ―33―
Ref. code Name Description Setting Range [Default]
F00.18 Reverse 0,1 [0]
This function is valid when F00.11 = 0,1,2.
0: Permitted.
1: Prohibitted.
• Inverter responds to FWD command only. If frequency < 0Hz, inverter will run at zero-frequency.
• Inverter will not respond to REV commands at stop status; during running, if inverter receives REV
command, it will accelerates to stop.
F00.19 Dead time of direction switch 0.0 - 3600.0 [0.0s]
Defines the dead time of direction switch, namely, the time of zero-frequency output in the process of
direction switch.
5.2.2 F01: Protection of Parameters
Ref. code Name Description Setting Range [Default]
F01.00 User password 00000 - 65535 [00000]
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, to change any parameter, input correct password. Otherwise, all the
parameters cannot be changed but only read.
• When input correct password, by pressing button ( ) to exit to stop / run display status or by
detecting no press on the keypad within 5 minutes, the user’s password will be valid. To change
parameters, input correct password. It will restart when there is no press on the keypad within 5 minutes.
00000: Factory setting of HD3N-TC, namely user have not set password.
• If user unlocks the password, it means clearing the user’s password.
F01.01 Menu mode 000 - 111 [000]
Units:
• 0: Full menu mode. All function parameters can be displayed.
• 1: Checking menu mode. Only parameters different from factory setting can be displayed.
Tens: Unused
Hundreds:
• 0: Group F can check after setting password.
• 1: Group F can not check after setting password.
